Operating Conditions & Applications

PT Coupling Cam & Groove Fittings are not rated for compressed gas service which includes air and steam.

Specifications For Operating Conditions & Applications:

Materials
Features
Applications
Aluminum with Brass Cam Arms (HB) or
with 300 Series Stainless Steel Cam Arms
(HBS)
Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance.
Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
Stainless Steel with HBS Cam Arms
Excellent corrosion-resistant material that provides high strength at high temperatures, helps prevent contamination of product being transported, maintains cleanliness, and retains a lustrous appearance. Harder than brass.
Ideal for use with salt water, wastewater, and many chemicals; can also be used with hydraulic oil and coolants.
Brass with HB Cam Arms
A good resistance, less expensive than Stainless Steel. Softer and easier to thread than Stainless Steel and forms tight seals.
Ideal for use with water. Can also be used with hydraulic oil, coolants, gasoline, and petroleum products.
Ductile Iron
Excellent abrasion and wear resistance. Good strength and toughness characteristics.
Ideal for use with sand, grout, cement, and other abrasives.
Hard Coat Aluminum
This is a lightweight material with good abrasion resistance. Good corrosion and chemical resistance.
Use with sand and salt water applications, as well as hydraulic oil, coolants, gasoline and petroleum products.
Polypropylene
Glass-fiber reinforced for strength. Good abrasion and corrosion resistance. Good chemical resistance.
Color: Black
Use with water and coolants.
Food Grade Polypropylene
Fair abrasion resistance.
Color: White
Use with water and other food grade applications.
Nylon
Glass-fiber reinforced for strength. Good abrasion, corrosion, and chemical resistance.
Color: Green
Use with water, coolants, gasoline and varnish.
For more detailed use and materials list go to: Chemical Compatibility Database

SAFETY INSTRUCTIONS

See below to learn more about PT Coupling's recommended Safety Instructions.

Installation

The PT Coupling line of quick connect/disconnect couplings comes with a wide range of fittings including threaded, hose connection and flanged end. These couplings have been engineered to meet specific requirements with safety margins.

IT IS THE RESPONSIBILITY OF THE END USER TO COMMUNICATE TO THE DISTRIBUTOR, THE APPLICATION AND OPERATING CONDITIONS THE COUPLING WILL BE SUBJECTED TO. IT IS UP TO THE DISTRIBUTOR TO SUPPLY THE CORRECT COUPLING FOR THE APPLICATION. PT COUPLING IS AVAILABLE TO HELP YOU WITH A PROPER COUPLING RECOMMENDATION.

For the type of application required, care must be taken to ensure proper connection and a positive seal. Improperly fitted or applied connections can result in serious accident and/or downtime. Under no circumstances shall the recommended pressure rating of the couplings be exceeded.

Operation

PT Coupling couplings provide for quick and frequent connection by means of the camming action on the groove surface of the male adapter. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then closed simultaneously to produce a uniform gasket compression between the seal surfaces.

The compression on the gasket produces a seal when torque is applied to the cam arms. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Cam arms must be in the full closed position for proper locking of coupling.

Gasket deterioration and excessive wear on cam, groove, and seal surfaces can reduce the performance of the coupler. Periodic inspection and servicing will ensure an efficient and safe performance.

Maintenance

Couplings should be well-maintained and inspected, particularly when the conditions of service include high working pressure and/or transfer or storage of hazardous materials. Periodic inspection and testing will detect signs indicating deterioration, damage, or loss of performance before failure.

Gaskets

The recommended seal material for a particular application has its limitations. Initial installation of a seal material should be followed by frequent inspections. This will help establish the routine inspection and service cycle.

Replacement is required when gasket becomes hard, brittle, or otherwise loses the characteristics required to perform in the intended manner.

Couplers

Periodically check seal surfaces on both coupler and adapter for signs of wear or corrosion. The adapter should be checked for excessive wear on the groove surface where contact is made with cam arms.

Cam arm and pin should also be periodically inspected for excessive wear. Worn or otherwise damaged cam arms and pins can prevent the coupler from operating in the intended manner.

To replace worn cam arm and pin, remove cam pin with hammer and punch. Install properly selected new cam arm and pin making sure the cam arm is positioned in the proper direction. The cam arm handled should always be pointed away from the female end of the cam and groove connection when the arm is in the closed position. Safety goggles should be worn during this procedure.

Domestic Fitting Recommended Operating Conditions

Material
Gasket
Size
Max. Allowable Working Pressure [MWAP] (PSI)*
Heavy Duty Max. Allowable Working Pressure [MAWP] (PSI)
Metal Couplings / Fittings
Standard Gaskets are Buna, any variation must be specified
1/2", 3/4 x 1/2", 3/4", 1", 1-1/4", 1-1/2", 2"
250
500


2-1/2", 3"
200
400


4"
150
300


5", 6"
75
150


8", 10" 12"
50
N/A
Non-Metal Couplings
Standard gaskets are Buna N any variation must be specified.
3/4", 1", 1-1/4" 1-1/2", 2""
100
N/A


3", 4"
50
N/A

*NOTE: Above maximum allowable working pressures are based on operating temperatures less than 100°F. If operating temperatures exceed 100°F, use temperature derating factor from table below.

Locate the correct factor from the table in the "Temperature Derating Factors" table and multiply by the appropriate MAWP (psi) in the "Recommended Operating Conditions" table for the elevated temperature working pressure.

EXAMPLE: 2" Alum. at 250°F = 250 psi x 0.84 = 210 psi at elevated temperature.

Temperature Derating Factors

Temp.
(° F)
Alum.
Brass
Stainless Steel
Ductile
Iron
Carbon
Steel
Hast. C®
Carp. 20®
Monel®
Poly
Nylon
*Min.
-150 °F
-150 °F
-150 °F
-20 °F
-20 °F
-150 °F
-150 °F
-150 °F
-15 °F
-30 °F
100
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
150
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
NR
0.90
200
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
NR
0.60
250
0.84
1.00
1.00
1.00
1.00
1.00
1.00
1.00
NR
NR
300
NR
0.97
1.00
1.00
1.00
1.00
1.00
1.00
NR
NR
350
NR
0.95
1.00
1.00
1.00
1.00
1.00
1.00
NR
NR
400
NR
0.92
1.00
1.00
1.00
1.00
1.00
1.00
NR
NR
450
NR
0.90
1.00
1.00
1.00
1.00
1.00
1.00
NR
NR
*500
NR
NR
1.00
1.00
1.00
1.00
1.00
1.00
NR
NR

NR = Not Recommended

*These temperatures represent the extremes that can be handled by current gasket materials.

All registered trademarks are property of their respective owners.

Gasket Recommended Operating Conditions

PT Coupling's Standard Gaskets for Cam & Groove Fittings are Buna N.

GASKETS AVAILABLE AND THEIR PROPERTIES
Compound
Material Color
Color Code Stripe
Min. Temp. Range °F
Max. Temp. Range °F
Buna N (standard)
Black
Blue
-65
275
Buna N (Fuel Resistant)
Black
Two Blue
-65
275
Buna N (Hot Oil)
Black
Two Orange
-65
325
Neoprene
Black
White
-65
275
FKM
Green
N/A
-40
400
FKM
Black
Green
-40
400
Thiokol®
Black
Yellow & Green
-65
225
Natural Rubber
Tan
N/A
-65
250
White Buna (Food)
White
N/A
-65
275
Silicone
Rust
N/A
-150
500
Hypalon®
Black
Red or Yellow
-65
300
EPDM
Black
Yellow
-65
300
EPDM (Fire Hose)
Black
Red or Yellow
-65
300
PTFE Enveloped
White Translucent
N/A
N/A
N/A
Neoprene Filler
Black
White
-65
275
Buna Filler
Black
Blue
-65
275
FKM Filler
Black
Green
-40
400
EPDM Filler
Black
Yellow
-65
300
PTFE Encapsulation
Transparent
N/A
N/A
N/A
Silicone Filler
Rust
N/A
-75
450
FKM Filler
Black
N/A
-40
400

All registered trademarks are property of their respective owners.

PT PAC Fittings Recommended Operating Conditions

The following table is rated to the PT PAC / Import products.

PT PAC/IMPORT PRESSURE RATINGS
Size
Max. Allowable Working Pressure [MWAP] (PSI)*
1/2" through 2"
250
2-1/2"
150
3"
125
4"
100
5" through 6"
75
8"
50
